ZP2V Vacuum Safety Valves — A/B Port Configurations (03–10)
ZP2V Vacuum Safety Valves — A/B Port Configurations (03–10)
Compact vacuum safety valves for compatible industrial vacuum circuits, suction-cup systems and automated handling equipment. Select the complete listed model code to match the inlet and outlet interface arrangement shown in the relevant drawing.
Quick Model Finder
- Choose the A or B configuration: select the exact listed prefix and port-code combination, such as A5, A01, AG1, B5, B01 or BG1.
- Check both interfaces: confirm the inlet and outlet thread or push-in connection before ordering. A change in the code can change the interface arrangement.
- Choose the final 03, 05, 07 or 10 code: this is a listed configuration code. Compare the selected drawing and the complete model code before substituting.
- Confirm application fit: verify vacuum level, tubing or thread compatibility, installation clearance and the workpiece-handling application before installation.
Product-code guide
ZP2V-[port configuration]-[03/05/07/10]: select the exact listed port-configuration code and final configuration code as one complete model. Do not interchange different A/B, thread or push-in configurations without checking the interfaces.
Suitable for
- Industrial vacuum lines and suction-cup circuits
- Robotic end-effectors and automated handling equipment
- Replacement or configuration work for compatible pneumatic systems
- Compact inline vacuum components for industrial systems after compatibility checks
Before use
Confirm the complete product code, inlet and outlet interfaces, selected drawing, vacuum level, operating environment, tubing or thread specification, payload and installation clearance before use. No food-contact, medical, lifting-safety or regulatory certification is claimed.
FAQ
Can I interchange models with different port codes? Treat each complete model as a separate configuration and compare both interfaces before substitution. What does the final code mean? Select the listed 03, 05, 07 or 10 configuration only after confirming the complete selected model code and drawing.
