Custom Non-Standard Robot Joint Components | Made to Drawing
From your drawing to your custom component. Send the part specification, material and quantity for project review.
Each part is quoted to the approved drawing. Material, tolerances, finish, minimum quantity and lead time are confirmed before ordering.
Quotation-only service. Product images illustrate manufacturing examples, not a ready-to-ship set. Please obtain a confirmed quotation before payment.
Include dimensions, units, drawing revision and critical tolerances.
Tell us the material grade, finish and quantity for each part.
Review feasibility, price, delivery and inspection requirements.
Custom Non-Standard Robot Joint Components
Made to your drawings, samples and technical requirements. This product page is for custom and non-standard robot joint housings, flanges, bearing seats, actuator housings, structural links and related precision-machined components.
Quotation required before ordering. Final price, quantity, production lead time, inspection and shipping are confirmed in writing after reviewing your drawing and requirements.
Custom manufacturing scope
- Robot joint housings and actuator housings
- Joint flanges, mounting interfaces and bearing seats
- Structural arms, links, brackets and support components
- Motor, reducer, encoder and cable-routing interfaces
- Prototype, replacement and small- or medium-batch components
The images show representative custom-machining concepts. They do not define a standard model or fixed dimensions. Delivered parts follow the approved drawing, revision and written quotation.
Technical information required for quotation
- Drawing or model: dimensioned PDF plus STEP/STP, IGES, DWG or DXF files when available. State the controlling drawing number and revision.
- Application: robot type, joint position, installation method, operating environment and whether the part is a new design or replacement.
- Critical interfaces: overall dimensions, shaft or bore sizes, flange diameter, bolt circle, mounting holes, bearing seats, motor/reducer/encoder interfaces and cable passages.
- Material: required alloy or material grade, together with any hardness or heat-treatment requirement.
- Tolerances: dimensional tolerances, fits, datums, concentricity, runout, flatness, perpendicularity and any critical geometric controls.
- Surface requirements: finish, roughness, anodizing, plating, passivation, coating, color, marking or other treatment.
- Loads and operating conditions: torque, radial/axial load, speed, duty cycle, shock, vibration, temperature, contamination and corrosion exposure where relevant.
- Inspection and documentation: critical-dimension reports, material documents, first-article requirements or other agreed acceptance records.
- Quantity and delivery: prototype quantity, order quantity, expected repeat volume, requested delivery date and destination.
Custom order process
- Send the drawings, sample details and application requirements.
- BOLTTE reviews manufacturability, critical interfaces, material, tolerances, inspection scope and quantity.
- Both parties confirm the drawing revision, final quotation and lead time in writing.
- Production and inspection follow the approved requirements.
Please do not place an order based only on the placeholder price. Request and confirm a project-specific quotation first.
Custom robot joint component examples
Request a project quotation
Upload drawings and project requirements, or contact BOLTTE with your application, material, tolerances and quantity.
