Custom Machined Gear Solutions | Spur, Worm & Helical
From your drawing to your custom component. Send the part specification, material and quantity for project review.
Each part is quoted to the approved drawing. Material, tolerances, finish, minimum quantity and lead time are confirmed before ordering.
Quotation-only service. Product images illustrate manufacturing examples, not a ready-to-ship set. Please obtain a confirmed quotation before payment.
Include dimensions, units, drawing revision and critical tolerances.
Tell us the material grade, finish and quantity for each part.
Review feasibility, price, delivery and inspection requirements.
Custom Machined Gear Solutions
Non-standard spur, worm and helical gears made to your drawings, samples and application requirements.
- Custom tooth geometry, bore, module, pitch and keyway options
- Suitable for prototypes, replacement parts and small-batch production
- Material and finish can be confirmed from your drawing or sample
Quotation required before ordering. Final price, quantity, production lead time, inspection and shipping are confirmed in writing after reviewing your drawing and requirements.
Custom Gear Manufacturing Details
This made-to-order service covers non-standard spur gears, helical gears, worm gears and worm shafts for prototypes, replacement parts and repeat production. Parts are manufactured to the approved drawing, sample or written technical specification rather than supplied as a generic stock gear.
Gear features we can review
- Module or diametral pitch, tooth count, pressure angle, helix angle and rotation direction.
- Outside diameter, pitch diameter, face width, bore, hub, keyway, spline, set-screw holes and other mounting details.
- Center distance, backlash, contact pattern, load, speed and operating environment where these affect the design.
- Steel, stainless steel, brass, bronze and engineering plastics, with heat treatment or surface finish when specified.
Recommended information for quotation
Please send a PDF drawing and, when available, a STEP/DWG/DXF file. Include gear type, dimensions, material, quantity, critical tolerances, heat treatment, surface finish and application details. For a replacement gear, clear photos and an undamaged sample can help our engineering review.
Production and quality workflow
- Drawing, sample and application review.
- Manufacturing feasibility, material and quotation confirmation.
- Drawing approval and prototype or first-article production when required.
- Gear cutting or machining, secondary operations, finishing and cleaning.
- Inspection against the approved drawing, followed by protective packing and shipment.
Custom-order note: Final price and lead time depend on geometry, material, tolerance, quantity and finishing requirements. Product images show representative manufacturing capabilities; the delivered part will follow the approved drawing and written quotation.
